Stainless steel mixing tanks in brewing systems are crucial for mixing and stirring ingredients. Their corrosion resistance and durability ensure a clean and efficient brewing process, maintaining the quality and consistency of the beer.
Stainless steel mixing tanks in brewing systems are crucial for mixing and stirring ingredients. Their corrosion resistance and durability ensure a clean and efficient brewing process, maintaining the quality and consistency of the beer.
Stable Structure: The tank body is made of integrated steel plate, with only one weld seam on the sidewall of the cylinder, which increases the structural strength of the tank. The dished heads are stamped from high-purity stainless steel plates of a Japanese brand, HOKKAI, or conical heads can be chosen to meet budget-friendly options.
Constant Pressure: The test pressure of all YME tanks is 2 to 3 times the normal working pressure, ensuring the pressure-bearing capacity of the tank under extreme conditions by increasing the design pressure value of the tank during the design phase and in the factory.
Corrosion Resistance,High Temperature Resistance: The inner and outer surfaces of the tank body, tank supports, and welds are all polished, and the components used all comply with hygienic standards, suitable for high-temperature, high-pressure, and acidic or alkaline environments.
Easy Transportation: All tanks are equipped with lifting lugs at the top and support brackets at the bottom for forklift transportation. Adjustable feet or wheels are installed under the support legs for easy movement of the tanks during on-site installation. Special brackets are also provided to support the tanks during transportation.
Easy Cleaning, Simple Maintenance: YME's designers will add dedicated CIP cleaning balls or manual cleaning devices for stainless steel tanks based on the customer's site usage. Manways are installed on the top and sidewalls of the tanks for easy cleaning of the tank interiors from the top and sides.
Head Space, 10~25%
Design Pressure, 2bar~6bar
Inside Finish, 2B/mirror
Outside Finish, #4
Inner Shell Roughness below to 0.6um
Four Tank Cylindrical Legs with Adjustable Feet/wheels
Internal Picked and Passivated Surface and Seam
Exterior Welds, Grounded and Polished to #4
All apertures flared both inside & out, no corners could harbor dirt
CIP Spray Ball Assembly
Pressure Vacuum Relief Valve
Set of Hop adding port
Side Oval Manway
Sanitary Thermowell
As a professional supplier of stainless steel mixing tanks, we are committed to providing high-quality, customized mixing solutions for various industries to help your brewing process reach new heights.
Our stainless steel mixing tanks are made of high-quality 304 or 316L stainless steel with excellent corrosion resistance and durability, ensuring long-term stable operation in a variety of harsh environments. The inner surface of the tank is finely polished and smooth with no dead ends, meeting strict hygiene standards for easy cleaning and sterilization to prevent product contamination. In addition, the tank can be designed as single-layer, double-layer or triple-layer structure according to the requirements, and supports a variety of heating and cooling methods, such as electric heating, steam heating or circulating water cooling, in order to meet the requirements of different processes for temperature control. As for the mixing system, we provide various forms of agitators, including anchor, paddle, propeller, etc., which can be customized according to the material characteristics and process requirements to ensure uniform and efficient mixing. The top of the tank is equipped with manholes, sight glasses, breathing valves and other accessories to facilitate operation and monitoring. The bottom of the tank is designed with a discharge port to ensure thorough material discharge and reduce residue. In addition, the tank can be equipped with optional CIP cleaning system to realize online cleaning, simplify the maintenance process and improve production efficiency.
Applications
Our stainless steel mixing tanks are widely used in food and beverage, pharmaceutical, chemical and cosmetic industries. In the field of food and beverage, it can be used for brewing beer, blending fruit juice, dairy products, syrup, etc.; in the pharmaceutical industry, it is suitable for the preparation and storage of medicinal liquid; in the chemical industry, it can be used for mixing all kinds of chemical reagents and solutions; and in the cosmetic industry, it can be used for the production of lotions and creams.
Customized Services
We understand that every customer has different needs, so we offer a full range of customized services. From tank capacity, structural form, mixing method to heating and cooling system, we can design and manufacture according to your specific requirements to ensure that the equipment perfectly fits your production process.
Quality Assurance
Quality is our lifeline. All the equipments are strictly tested before leaving the factory to ensure that all the indexes are in accordance with the relevant standards. We have a perfect after-sales service system to provide you with equipment installation, commissioning, training and other support to ensure that you have no worries.
If you are interested in our stainless steel mixing tank, or have any questions, please feel free to contact us. Our professional team will be happy to serve you and provide the most suitable solution for you.
Send us your request for quotation and we will generate a quote with everything you need for your brewing equipment.
